Aquapure Industrial Water Purification System with Ultra-Filtration and EDI Process Resin and Plastic Media Core Components

Large Image : Aquapure Industrial Water Purification System with Ultra-Filtration and EDI Process Resin and Plastic Media Core Components

Product Details:

Place of Origin:	Hebei, China
Brand Name:	HUAYU
Certification:	ISO9001:2015

Contact Now

Detailed Product Description

Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Core Components:	Pump, Engine, Motor, PLC	Warranty:	1 Year
Productivity:	5000L/Hour	Weight (kg):	1000
Processing Type:	Reverse Osmosis	Dimension(LWH):	160 70 70
Power:	70 KW	Voltage:	220V, 380V, 110V
Application:	Wastewater Treatment	Product Name:	Uf Membrane System
Core Technology:	UF Process	Lead Time:	About 21 Days

Product Description

Ultrapure Water Equipment
The EDI equipment offered by Hebei Huayu Environmental Engineering Co., Ltd. is ingeniously positioned after the reverse osmosis system. It serves as a sophisticated replacement for the conventional mixed bed ion exchange technology (MB-DI). This innovative approach is designed to consistently deliver ultrapure water of the highest stability. When compared to the traditional mixed ion exchange technology, EDI technology stands out with remarkable advantages that cater to modern needs:

Consistent and Superior Water Quality.
Effortless Fully Automated Control
No Downtime Due to Regeneration Processes
Eliminates the Requirement for Chemical Regeneration
Cost-Efficient Operation
Compact and Space-Saving Design

Detailed Photos

Working Principle

Our Advantages

Product Parameters

Parameters	HYHJ-RO/EDI-5T
Machine Size(LWH)	6500mm/850mm/2200mm
Control mode	Fully automatic operation
Device power	AC/380V/50HZ
Raw water pump	Q=12m³/H H=30m
First-stage high-pressure pump	Q=12m³/H H=100m
Two-stage high-pressure pump	Q=8m³/H H=80m
Reverse osmosis membrane vessels	3 core 8 inches
EDI booster pump	Q=6m³/H H=30m
EDI module	5000L/H
Quartz sand filter	φ1000×2200mm
Activated carbon filter	φ1000×2200mm
Precision filters	7 core 40 inches
Precision filter element	40''5μm
Scale inhibitor/PH dosing pump	Q=1L/H H=50m
Scale inhibitor/PH dosing box	40L
Primary reverse osmosis membrane	8040
Secondary reverse osmosis membrane model	8040

Product Application
