Product Details:
|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
---|---|---|---|
Core Components: | Pump, Engine, Motor, PLC | Warranty: | 1 Year |
Productivity: | 5000L/Hour | Weight (kg): | 1000 |
Processing Type: | Reverse Osmosis | Dimension(L*W*H): | 160 70 70 |
Power: | 70 KW | Voltage: | 220V, 380V, 110V |
Application: | Wastewater Treatment | Product Name: | Uf Membrane System |
Core Technology: | UF Process | Lead Time: | About 21 Days |
Our company specializes in designing ultrafiltration membrane systems in our laboratory, with an ultrafiltration equipment capacity of 1000L/H. The system utilizes municipal tap water as the raw water source, and the conductivity of the RO water purifier for industrial use is maintained below 10 µS/cm. With the robust performance and strong capabilities of our 10,000 LPH UF system, we are currently engaged in the process design, engineering construction, equipment supply, installation, and commissioning of this project.
Parameters | HYHJ-RO/EDI-5T |
Machine Size(L*W*H) | 6500mm/850mm/2200mm |
Control mode | Fully automatic operation |
Device power | AC/380V/50HZ |
Raw water pump | Q=12m³/H H=30m |
First-stage high-pressure pump | Q=12m³/H H=100m |
Two-stage high-pressure pump | Q=8m³/H H=80m |
Reverse osmosis membrane vessels | 3 core 8 inches |
EDI booster pump | Q=6m³/H H=30m |
EDI module | 5000L/H |
Quartz sand filter | φ1000×2200mm |
Activated carbon filter | φ1000×2200mm |
Precision filters | 7 core 40 inches |
Precision filter element | 40''5μm |
Scale inhibitor/PH dosing pump | Q=1L/H H=50m |
Scale inhibitor/PH dosing box | 40L |
Primary reverse osmosis membrane | 8040 |
Secondary reverse osmosis membrane model | 8040 |
